QUIET DUO™ ELR Kit,
only 700 mA Inrush
15 Series Electric Strike
QUIET DUO™ ELR Kit,
only 700 mA Inrush

The SDC LR100 Series Electric Latch Retraction Kit enables electric access control and dogging of mechanical exit devices. When energized the motor retracts the exit device latch and pulls the pushpad on most devices into the dogged (depressed) position enabling momentary or sustained push and pull operation of the door.

New version now available for Jackson device

QUIET DUO™ LR100 Series available for these brands:

• Von Duprin
• SDC
• Hager
• Sargent
• Yale
• PHI
• K2
• Arrow
• Pamex
• Corbin Russwin
• Dor-O-Matic
• TownSteel
• Marshall Best
• Adams Rite
• IDC
• Falcon
• Marks
• Jackson


Features
  • Motorized Electric Latch Retraction & Dogging for Fire Rated & Non Fire Rated Devices
  • Retrofits select exit device brands without removing device from the Door
  • Only Latch head cover and end cover plate removable required for most other brands
  • Low 700mA Inrush, 180 mA Continous
SDC LR100VDK-EM External Module. Designed for Von Duprin Devices cut down to 30".
Powering a LR100VDK Latch Retraction Kit using a Von Duprin PS873 or PS914 Power Supply
Von Duprin Solenoid Removal Instructions
