1560 Series

Concealed Electromagnetic Shear Locks

SDC HiShear® electromagnetic shear locks are designed, engineered and built in America for openings that require an architecturally superior appearance. Long recognized as a cut above alternatives on the market, SDC shear locks provide high security with a failsafe locking mechanism to meet a variety of door opening applications. The patented HiShear® design incorporates a floating armature assembly and special alloy steel locking tabs on both the lock and armature assemblies, that may be adjusted both vertically and laterally to compensate for wide door gaps and warped or misaligned doors. Advanced electronic circuitry incorporates a door alignment relock sensor as well as an automatic sensing dual voltage input. Noise dampeners greatly reduce the noise associated with locking and unlocking when compared to other shear locks on the market.

HiShear® magnetic shear locks are ideal for use on commercial grade hollow metal and wood doors, metal frames and Herculite doors with top rails.

The innovative 1560 series concealed electromagnetic shear locks are available with 2000lbs and 2700lbs holding force for standard 13/4” to 2” frames with internal electronics, as well as narrow 11/4” to 11/2” frames with external electronics.

1561
Concealed Shear Lock, Integrated Electronics, 2000lbs

1562
Concealed Shear Lock, External Electronics, 2000lbs

1565
Concealed Shear Lock, Integrated Electronics, 2700lbs

1566
Concealed Shear Lock, External Electronics, 2700lbs

u Features
  • Fully concealed mortise design
  • Floating armature assembly
  • Special alloy steel shear tabs
  • Auto-sensing dual voltage
  • Door alignment relock sensor
  • Adjustable lateral and vertical alignment
  • Noise dampeners
